11 V turn 12v10a voltage converter/5 V turn 12v2a voltage converter/dc-dc

Changzhou Geng Tai Electronics Co., Ltd
Contact Now

11 V turn 12v10a voltage converter/5 V turn 12v2a voltage converter/dc-dc

Brand Name : G·T

Model Number : GTK-12-48- 100

Place of Origin : China

MOQ : 1 PCS

Price : USD10-20 PCS

Payment Terms : T/T

Supply Ability : 500 pcs per month

Delivery Time : 10-15 working days upon order quantity

Packaging Details : Neutral factory box

Color : as shown in the figure

Warranty : 2 Years

Size : 50*40.5*22mm

Contact Now

11 V turn 12v10a voltage converter/5 V turn 12v2a voltage converter/dc-dc


Specification:

Model GTK-0511
The properties of module Non-isolated BUCK
Input Voltage DC5V-11V
Output Voltage DC12V
Output Current 2A -10A (optional)
Output Power 24W-120W (optional)
Conversion Efficiency >93%
Ripple 40mV
Power Consumption 25mA
Working Temperature -40℃~+85℃(industrial-grade)
Two Input red lines 13~14MM
Length of line 50 CM

Size and

Weight

1A-4A 50*40.5*22 97g
10A 74*74*32 260g
Waterproof Rate IP67

Function:

Protection of over current, over voltage, over temperature, short circuit

notice: No backconnection protection

11 V turn 12v10a voltage converter/5 V turn 12v2a voltage converter/dc-dc
